Availability:
50 in stock
₨11,000
50 in stock
OVERVIEW:
Connectable to HDTVI, AHD and analog cameras
Long distance transmission over UTP and coaxial cable
One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
Supports real-time 1080p lite of all channels and when enabled, the image effect is similar with 1080p
HDMI/VGA output at up to 1920 × 1080 resolution
4/8/16-ch synchronous playback at up to 720p resolution
Smart search for efficient playback
One self-adaptive 10/100Mbps network interface
Output bandwidth limit configurable
Specifications
| BRAND | Hikvision |
|---|
| Computers Specs | |
| Power Supply Type | 12V DC |
| GAMING ACCESSORIES | |
| Audio in/out ports | 1-ch |
| INPUT | |
| IP Camera Inputs | 32 channels |
| Summary | |
| Power Consumption | ≤ 8W |
| Weight | ≤ 0.8 kg / 1.8 lb(without hard disks) |
| HARDWARE FEATURES | |
| Network Protocols and Features | TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Networking interface | 1; 10M / 100M self-adaptive Ethernet interface |
| Interface | |
| Network Interface | 2 x 10/100/1000 Mbps self-adaptive Ethernet interface |
| Output | |
| Video Output | 1 x HDMI output 1 x VGA output (independent) |
| Type | |
| Support Camera Type | Support HDTVI input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz, Support AHD input: 720P/25Hz, 720P/30Hz, support CVBS input |
| General Specification | |
| Chassis (W x D x H) | 19″ 1.5 RU |
| Compression | H.264, H.265, H.264+, and H.265+ |
| Decoding | 2 x DCI 4K / 12 x 1080p (local) |
| Dual Stream | Support |
| Memory | Up to 6 TB capacity for each disk |
| Recording Resolution | When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF; When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF |
| Support | Control Client (local & remote) Web Client Mobile Client Third-party cameras Alarm management Map Two-way audio Broadcast PTZ control Fisheye expansion People counting report Heat map report Traffic flow report SSD support (64 GB) |
| Working Condition | 32 to 113°F (0 to 45°C) Humidity: 10-90% |
| Dimension | 200 × 200 × 45mm (7.9 × 7.9 × 1.8 inch) |
| Input | |
| Video Compression | H.264,H.264+ |
| Video Input | 4-ch BNC interface (1.0Vp-p, 75 Ω) |
| INTERFACE | |
| HDMI | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| USB | 2 USB 2.0 Interfaces |
