OVERVIEW:
Connectable to HD‐TVI, AHD, network and analog cameras
Support HIKVISION‐C protocol for connecting camera over coax
Simultaneous HDMI and VGA outputs at up to 1080p resolution.
New GUI and support starting record with one key
Instant playback for assigned camera during multi‐channel live view mode
4/8/16‐ch synchronous playback at 720p resolution
and reverse playback for multi‐camera
Smart playback to go through less effective information
Manual video quality diagnostics
Customi
ation of tags, searching and playing back by tags
Specifications
| BRAND | Hikvision |
|---|
| Computers Specs | |
| Power Supply Type | 12V DC |
| Stream Processors | Video/Video&Audio |
| Hard Disk | 1 SATA interfaces |
| GAMING ACCESSORIES | |
| Audio in/out ports | 1-ch |
| Summary | |
| Capacity | Up to 6 TB capacity for each disk |
| Power Consumption | ≤20W(without hard disks) |
| Weight | ≤ 1.2 kg / 2.6 lb(without hard disks) |
| Antenna | |
| Dimensions | 285 × 210 × 45 mm (11.2 × 8.3 × 1.8 inch) |
| HARDWARE FEATURES | |
| Encoding Method | When 1080p Lite mode not enabled: 3 MP/1080p/720p/WD1/4CIF/VGA/CIF; When 1080p Lite mode enabled: 3 MP/1080p lite/720p lite/WD1/4CIF/VGA/CIF |
| Network Protocols and Features | TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS |
| Networking interface | 1; 10M / 100M self-adaptive Ethernet interface |
| Interface | |
| Network Interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
| Output | |
| Audio Output | 1-ch RCA(Linear, 1kΩ) |
| HDMI/VGA Output | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| Video Output | 1 x HDMI output 1 x VGA output (independent) |
| Type | |
| Support Camera Type | Support HDTVI input: 720P/25, 720P/30, Support AHD input: 720P/25, 720P/30, CVBS |
| General Specification | |
| Compression | H.265 |
| Frame Rate | 1/16 fps ~ Real time frame rate |
| Connectivity | 128 |
| Input | |
| Analog Video Input | 4-ch/8-ch/16-ch |
| Audio Compression | G.711u |
| Video Compression | H.264,H.264+ |
| Video Input | 8 Channels |
| INTERFACE | |
| USB | 2 USB 2.0 Interfaces |
