OVERVIEW:
Connectable to HDTVI, AHD and analog cameras
Up to 2-ch 4 MP IP cameras input
Long distance transmission over UTP and coaxial cable with max. 1200m for the 720p and max. 800m for the 1080p HDTVI signal
One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
Full channel recording at up to 3 MP resolution
Independent CVBS output improves compatibility at the most possibility and serves as the aux output or live view output only
Smart search for efficient playback
Supports the 3rd party cloud storage (Dropbox/Google Drive/Microsoft OneDrive)
One gigabit Ethernet network interface (for DS-7208HUHI-F1/N)
Output bandwidth limit configurable
Specifications
| BRAND | Hikvision |
|---|
| POWER | |
| Consumption | ≤ 20W(without hard disks) |
| Summary | |
| Capacity | Up to 6 TB capacity for each disk |
| Weight | ≤2 kg(4.4lb) |
| HARDWARE FEATURES | |
| Working Humidity | 10% ~ 90% |
| Power Supply | 12V DC |
| Interface | |
| Audio Input Interface | 4-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Network Interface | 2; 10M / 100M / 1000M self-adaptive Ethernet interfaces |
| Output | |
| Alarm Output | 1-ch |
| HDMI/VGA Output | 1-ch,4K (3840 × 2160)/30Hz,2K(2560 ×1440)/60Hz, 1920 ×1080/60Hz, 1280 ×1024/60 Hz, 1280 ×720/60Hz, 1024 ×768/60 Hz |
| TECHNICAL SPECIFICATION | |
| Working temperature | -10 oC ~+55 oC (14 oF ~ 131 oF) |
| Type | |
| Stream Type | Video/Video&Audio |
| Support Camera Type | Support HDTVI input: 3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz, Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz Support CVBS input |
| General Specification | |
| Chassis | Standard 1U chassis |
| Frame Rate | Main stream:3 MP@15fps;1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) Sub-stream:WD1/4CIF@12fps;CIF/QVGA/QCIF@25fps (P)/30fps (N) |
| Recording Resolution | Mainstream:3Mp@15fps/1080p/720p/WD1/4CIF Sub-stream:WD1/4CIF@12fps(non-real-time);CIF/QVGA/QCIF(real-time) |
| Dimensions | 315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
| Interface Type | 1 SATA Interface |
| Input | |
| Video Compression | H.264,H.264+ |
