Availability:
50 in stock
₨15,140
50 in stock
OVERVIEW:
H.264 ,H.264+& Dual-stream video compression
Support HD-TVI, IPC,AHD and analog cameras with adaptive access
Support Cloud storage(One Drive, Google Drive or Drop Box)
Simultaneous HDMI/VGA output at up to 1920 × 1080 resolution for DS-7204HUHI-F2/N and 4K (3840 × 2160) resolution for HDMI output of DS-7208/7216HUHI-F2/N
Long transmission distance over coax cable
Up to 4/8-ch synchronous playback at 1080p resolution
playback at up to 256X speed
Specifications
| BRAND | Hikvision |
|---|
| POWER | |
| Consumption | ≤ 20W(without hard disks) |
| Summary | |
| Capacity | Up to 6 TB capacity for each disk |
| Playback Resolution | 3MP/1080P/720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF |
| Weight | ≤2 kg(4.4lb) |
| Antenna | |
| Dimensions | 380 × 320 × 4 8 mm (1 5.0 × 12.6 × 1.9 inch) |
| HARDWARE FEATURES | |
| Network protocols | TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS,ONVIF |
| Working Humidity | 10% ~ 90% |
| Power Supply | 12V DC |
| Interface | |
| Audio Input Interface | 4-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Network Interface | 1; 10M / 100M / 1000M self-adaptive Ethernet interface |
| USB Interface | 1 USB 2.0 Interface & 1 USB 3.0 Interface |
| Output | |
| Alarm Output | 1-ch |
| TECHNICAL SPECIFICATION | |
| Working temperature | -10 oC ~+55 oC (14 oF ~ 131 oF) |
| Type | |
| Stream Type | Video/Video&Audio |
| Support Camera Type | Support HDTVI input: 3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz, Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz Support CVBS input |
| General Specification | |
| Recording Resolution | 3 MP/1080p/720p/WD1/4CIF/VGA/CIF |
| Remote connections | 128 |
| Interface Type | 2 SATA Interfaces |
| Input | |
| Alarm Input | 4-ch |
| Audio Input | 16-ch |
| Video Compression | H.264,H.264+ |
