OVERVIEW:
Connectable to AHD, HD-TVI, network and analog cameras;
Support HIKVISION-C protocol for conne ng camera over coax;
Support enabling H.264+ to ensure high video quality with lowered bitrate;
Provide HDMI, VGA and CVBS outputs, and simultaneous HDMI/VGA output at up to 1920×1080p resolu on;
One-key recording configurable;
Redundant recording and holiday recording;
Main stream and sub-stream parameters configurable for simultaneous recording;
Support channel-zero encoding;
Support 1080p lite mode enabled to realize the real- me 1080p lite and 720p lite resolu ;
Instant playback for assigned camera in live view mode;
Up to 4/8-ch synchronous playback at 1080p resolu on;
Playback at up to 256X speed
Document:
hikvision-ds-7208hqhi-f1-n-dvr
Specifications
| BRAND | Hikvision |
|---|
| POWER | |
| Consumption | ≤ 20W(without hard disks) |
| Summary | |
| Capacity | Up to 6 TB capacity for each disk |
| Playback Resolution | 3 MP/1080p/720p/VGA/WD1/4CIF/CIF |
| Weight | ≤2 kg(4.4lb) |
| HARDWARE FEATURES | |
| Network protocols | TCP/IP, PPPoE, DHCP,Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS,ONVIF |
| Power Supply | 12V DC |
| Interface | |
| Audio Input Interface | RCA (2.0 Vp-p, 1 kΩ) |
| Serial Interface | 1; standard RS-485 serial interface, half-duplex |
| Output | |
| CVBS Output | 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704×576,NTSC:704×480 |
| TECHNICAL SPECIFICATION | |
| Working temperature | -10 oC ~+55 oC (14 oF ~ 131 oF) |
| Type | |
| Stream Type | Video/Video&Audio |
| General Specification | |
| Chassis | Standalone 1U chassis |
| Remote connections | 128 |
| Dimensions | 315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
| Interface Type | 1 SATA Interface |
| Input | |
| IP Video Input | 2-ch Up to 2MP resolution |
