Availability:
50 in stock
₨18,400
50 in stock
OVERVEIW:
H.264 ,H.264+& Dual-stream video compression
Support HD-TVI, IPC,AHD and analog cameras with adaptive access
Support Cloud storage(One Drive, Google Drive or Drop Box)
HDMI and VGA output at up to 1920×1080P resolution,HDMI output at up to 4K(3840×2160) resolution for DS-7208HUHI-F1/N
Long transmission distance over coax cable
Up to 4/8-ch synchronous playback at 1080p resolution
playback at up to 256X speed.
Specifications
| BRAND | Hikvision |
|---|
| POWER | |
| Consumption | ≤ 20W(without hard disks) |
| Summary | |
| Capacity | Up to 6 TB capacity for each disk |
| Playback Resolution | 3MP/1080P/720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF |
| Weight | ≤2 kg(4.4lb) |
| HARDWARE FEATURES | |
| Network protocols | TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS,ONVIF |
| Dimensions ( W x D x H ) | 315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
| Power Supply | 12V DC |
| Interface | |
| Audio Input Interface | 4-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Serial Interface | 1; standard RS-485 serial interface, half-duplex |
| USB Interface | 1 USB 2.0 Interface & 1 USB 3.0 Interface |
| Video Input Interface | BNC (1.0 Vp-p, 75Ω) |
| Output | |
| Alarm Output | 1-ch |
| Audio Output | 1-ch RCA(Linear, 1kΩ) |
| CVBS Output | 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704×576,NTSC:704×480 |
| TECHNICAL SPECIFICATION | |
| Working temperature | -10 oC ~+55 oC (14 oF ~ 131 oF) |
| Type | |
| Stream Type | Video/Video&Audio |
| General Specification | |
| Chassis | Standard 1U chassis |
| Remote connections | 128 |
| Interface Type | 1 SATA Interface |
| Input | |
| Alarm Input | 4-ch |
| Analog and HD-TVI video input | 8-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
| Audio Input | 4-ch |
