Availability:
50 in stock
₨26,160
50 in stock
FEATURES:
Long distance transmission over UTP and coaxial cable: max. 1200m for 720p Turbo HD signal
One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
Supports 1080p lite of all channels and when enabled, the image effect is similar with 1080p
Two SATA interfaces (up to 6 TB capacity per HDD)
8/16-ch synchronous playback at up to 720p resolution
Smart search for efficient playback
Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
VQD (Video Quality Diagnostics)
Unlock pattern for device login for the admin and clear-text password available
Specifications
| BRAND | Hikvision |
|---|
| POWER | |
| Consumption | ≤ 20W(without hard disks) |
| Summary | |
| Capacity | Up to 6 TB capacity for each disk |
| IP Video Input Resolution | Up to 2 MP resolution |
| Playback Resolution | 1080p lite/720p/WD1/4CIF/VGA/CIF |
| Weight | ≤ 2 kg (4.4 lb) (without hard disks) |
| HARDWARE FEATURES | |
| Network protocols | TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS |
| Working Humidity | 10% ~ 90% |
| Power Supply | 12V DC |
| Interface | |
| Audio Input Interface | RCA (2.0 Vp-p, 1 kΩ) |
| Network Interface | 1; 10M / 100M self-adaptive Ethernet interface |
| USB Interface | 2 USB 2.0 Interfaces |
| Output | |
| Audio Output | 1-ch RCA(Linear, 1kΩ) |
| HDMI/VGA Output | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| TECHNICAL SPECIFICATION | |
| Working temperature | -10 oC ~+55 oC (14 oF ~ 131 oF) |
| Type | |
| Stream Type | Video/Video&Audio |
| Support Camera Type | Support HDTVI input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz, Support AHD input: 720P/25Hz, 720P/30Hz, support CVBS input |
| General Specification | |
| Dimensions | 380 × 320 × 48 mm (14.9 × 12.6 × 1.9 inch) |
| Frame Rate | Main stream: When 1080p Lite mode not enabled: For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) |
| Recording Resolution | When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF; When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF |
| Remote connections | 128 |
| Interface Type | 2 SATA Interfaces |
| Input | |
| Analog and HD-TVI video input | 16-ch BNC interface (1.0Vp-p, 75 Ω) |
| Audio Compression | G.711u |
| Audio Input | 1-ch |
| IP Video Input | 2-ch |
| Video Compression | H.264,H.264+ |
