Availability:
50 in stock
₨19,090
50 in stock
OVERVEIW:
Video Input and Transmission
Connectable to HDTVI, AHD and analog cameras
Up to 2-ch 1080p IP cameras input
Long distance transmission over UTP and coaxial cable Compression and Recording
One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
Supports real-time 1080p lite of all channels and when enabled, the image effect is similar with 1080p Video Output
HDMI/VGA output at up to 1920 × 1080 resolution Storage and Playback
Two SATA interfaces (up to 6 TB capacity per HDD)
8/16-ch synchronous playback at up to 720p resolution
Specifications
| BRAND | Hikvision |
|---|
| POWER | |
| Consumption | ≤ 20W(without hard disks) |
| Summary | |
| Capacity | Up to 6 TB capacity for each disk |
| Playback Resolution | 1080p lite/720p/WD1/4CIF/VGA/CIF |
| Weight | ≤ 2 kg (4.4 lb) (without hard disks) |
| HARDWARE FEATURES | |
| Working Humidity | 10% ~ 90% |
| Power Supply | 12V DC |
| Interface | |
| Audio Input Interface | RCA (2.0 Vp-p, 1 kΩ) |
| Network Interface | 1; 10M / 100M self-adaptive Ethernet interface |
| USB Interface | 2 USB 2.0 Interfaces |
| Output | |
| Audio Output | 1-ch RCA(Linear, 1kΩ) |
| TECHNICAL SPECIFICATION | |
| Working temperature | -10 oC ~+55 oC (14 oF ~ 131 oF) |
| Type | |
| Stream Type | Video/Video&Audio |
| General Specification | |
| Chassis | 10% ~ 90% |
| Dimensions | 380 × 290 × 48 mm (14.9 × 11.4 × 1.9 inch) |
| Remote connections | 128 |
| Interface Type | 2 SATA Interfaces |
| Input | |
| Analog and HD-TVI video input | 16-ch BNC interface (1.0Vp-p, 75 Ω) |
| Audio Compression | G.711u |
| Audio Input | 1-ch |
| IP Video Input | 2-ch Up to 2MP resolution |
| Video Compression | H.264,H.264+ |
