OVERVEIW:
Self-adaptive HDTVI/HDCVI/AHD/CVBS signal input
Connectable to H.265+/H.265/H.264+/H.264 IP cameras
Up to 4MP lite resolution for recording
HDMI output at up to 4K (3840 × 2160) resolution for DS-7216HQHI-K1
Long distance transmission over UTP and coaxial cable
4/8/16-ch synchronous playback
Specifications
| BRAND | Hikvision |
|---|
| POWER | |
| Consumption | ≤ 25W(without hard disks) |
| Summary | |
| Capacity | Up to 10 TB capacity for each disk |
| Weight | ≤ 2 kg (4.4 lb) |
| HARDWARE FEATURES | |
| Network protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS, ONVIF |
| Working Humidity | 10% to 90% |
| Power Supply | 12 VDC |
| Interface | |
| Network Interface | 1; 10M / 100M / 1000M self-adaptive Ethernet interface |
| USB Interface | 1 USB 2.0 Interface & 1 USB 3.0 Interface |
| Video Input Interface | BNC (1.0 Vp-p, 75Ω) |
| Output | |
| Audio Output | 1-ch RCA(Linear, 1kΩ) |
| TECHNICAL SPECIFICATION | |
| Working temperature | -10 oC to +55 oC (14 oF to 131 oF) |
| Type | |
| Stream Type | Video/Video&Audio |
| General Specification | |
| Dimensions | RCA (2.0 Vp-p, 1 kΩ) |
| Remote connections | 128 |
| Dimensions | 315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
| Interface Type | 1 SATA Interface |
| Input | |
| Analog and HD-TVI video input | 16-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
| Audio Compression | G.711u |
| Audio Input | 1; standard RS-485 serial interface, half-duplex |
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
