OVERVEIW:
H.264 & Dual-stream video compression
Support HD-TVI/analog/IP camera triple hybrid
Support both HD-TVI and analog cameras with adaptive access
Full channel@1080P resolution real-time recording
HDMI and VGA output at up to 1920×1080P resolution
Long transmission distance over coax cable
Support up to 16-ch synchronous playback
Document:
Specifications
| BRAND | Hikvision |
|---|
| POWER | |
| Consumption | ≤ 45W(without hard disks) |
| Summary | |
| Capacity | Up to 6 TB capacity for each disk |
| Playback Resolution | 1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF |
| Weight | ≤ 2Kg (4.4lb)(without hard disks) |
| HARDWARE FEATURES | |
| Network protocols | TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP?, HTTPS |
| Working Humidity | 10% ~ 90% |
| Power Supply | 12V DC |
| Interface | |
| Audio Input Interface | RCA (2.0 Vp-p, 1 kΩ) |
| Network Interface | 1; 10M / 100M / 1000M self-adaptive Ethernet interface |
| Serial Interface | 1; standard RS-485 serial interface, half-duplex |
| USB Interface | 2 USB 2.0 Interfaces |
| Video Input Interface | BNC (1.0 Vp-p, 75Ω) |
| Output | |
| Alarm Output | 4-ch |
| Audio Output | 1-ch RCA(Linear, 1kΩ) |
| HDMI/VGA Output | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| TECHNICAL SPECIFICATION | |
| Working temperature | -10 oC ~+55 oC (14 oF ~ 131 oF) |
| Type | |
| Stream Type | Video/Video&Audio |
| General Specification | |
| Chassis | 380mm 1U chassis |
| Recording Resolution | 1080p/720p/VGA/WD1/4CIF/CIF |
| Remote connections | 128 |
| Dimensions | 380 × 290 × 48mm (15.0 × 11.4 × 1.9 inch) |
| Interface Type | 2 SATA Interfaces |
| Input | |
| Alarm Input | 16-ch |
| Analog and HD-TVI video input | 16-ch,BNC interface(1.0Vp-p,75Ω) |
| Audio Compression | G.711u |
| Audio Input | 4-ch |
| IP Video Input | 2-ch 1080P |
| Video Compression | H.264 |
