Schneider NSX100F 4 Pole Molded Case Circuit Breaker, 36 kA
Key Features
- Range of product: EasyPact
- Product or component type: Circuit breakerEZCIOOH
- Circuit breaker name: Easypact EZCIOOH
- Device application: Distribution
- Poles description: 4P
- Protected poles description: 3t
- Network type: DC/AC
- Network frequency: 50/60 Hz
Brand:
Availability:
50 in stock
₨62,000
This ComPacT NSX100F is a complete 4P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 36kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 25A, 40A, 63A, 80A, 100A rating thermal-magnetic trip unit (TMD). TMD trip unit provides adjustable thermal overload protection and a fixed magnetic protection. This 4 poles version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC, and marine specifications. ComPacT NSX100F is part of Schneider Electric EcoStruxure Power architecture.
Specifications
| BRAND | Schneider |
|---|---|
| Ampere Rating | 100A, 16A, 25A, 40A, 63A, 80A |
Product Specifications
|
Range of product
|
easypact
|
|
product or component type
|
circuit breakerezciooh
|
|
circuit breaker name
|
easypact ezciooh
|
|
device application
|
distribution
|
|
poles description
|
4p
|
|
protected poles description
|
3t
|
|
network type
|
dc/ac
|
|
network frequency
|
50/60 hz
|
|
[in] rated current
|
60 a at 40 oc
|
|
(ui) rated insulation voltage
|
690 v ac 50/60 hz conforming to iec 60947-2
|
|
[uimpj rated impulse withstand voltage
|
6 kv conforming to iec 60947-2
|
|
[uel rated operational voltage
|
550 v ac 50/60 hz conforming to iec 60947-2 / 250 v dc conforming to iec 60947-2
|
|
breaking capacity code
|
h
|
|
breaking capacity
|
30 ka
|
|
suitability for isolation
|
yes conforming to iec 60947-2
|
|
utilisation category
|
category a
|
|
trip unit name
|
tm-d
|
|
trip unit technology
|
thermal-magnetic
|
|
trip unit rating
|
60 a at 50 oc
|
|
protection type
|
short-circuit protection / overload protection
|
|
pollution degree
|
3 conforming to iec 60947
|
|
standards
|
en/iec 60947-2 / gbi’t 14048.2 / en/iec 60947-1 / jis c8201-2-2
|
|
ip degree of protection
|
ip20 conforming to iec 60529
|
|
1k degree of protection
|
ik07 conforming to en 50102
|
|
ambient air temperature for operation
|
-25…70 c
|
|
ambient air temperature for storage
|
-35…85 c
|
Based on 0 reviews
Be the first to review “Schneider NSX100F 4 Pole Molded Case Circuit Breaker, 36 kA”
